7000 Series Planter Lift Assist Wheel

7000 Series Planter Lift Assist Wheel

Dual Planter List Assist provided for attaching planters to four, six, or eight Row Rip/Strips.  Quad Planter LIft Assist provided for attaching planters to twelve row Rip/Strips.  Different beam lengths provided for various row components and space required for seed planters.  Optional Weight Transfer kit adds additional hydraulic cylinder/accumulator system that distributes weight between the caster wheels on the rear and the front tires of the tractor.  Makes lifting and handling easier and safer.  With the use of the Weight Tranfer Kit, Planter Lift Assist Wheels can function without the seed planter attached as helper wheel to tractor lift system.

Description

Dual Planter List Assist provided for attaching planters to four, six, or eight Row Rip/Strips.  Quad Planter LIft Assist provided for attaching planters to twelve row Rip/Strips.  Different beam lengths provided for various row components and space required for seed planters.  Optional Weight Transfer kit adds additional hydraulic cylinder/accumulator system that distributes weight between the caster wheels on the rear and the front tires of the tractor.  Makes lifting and handling easier and safer.  With the use of the Weight Tranfer Kit, Planter Lift Assist Wheels can function without the seed planter attached as helper wheel to tractor lift system.

Available Models

Model #

70DLA (30-40) SHRT Dual Planter Lift Assist with 95" beam for 30" to 40" Rows

70DLA (30-40) MID Dual Planter Lift Assist with 95" beam for 30" to 40" Rows

70DLA (30-40) LNG Dual Planter Lift Assist with 95" beam for 30" to 40" Rows

70QLA (30-40) SHRT Dual Planter Lift Assist with 95" beam for 30" to 40" Rows

70QLA (30-40) MID Dual Planter Lift Assist with 95" beam for 30" to 40" Rows

70QLA (30-40) LNG Dual Planter Lift Assist with 95" beam for 30" to 40" Rows
